Inductive sensor M8 60 mm connector M8 NPN NC Sn = 4 mm
- ● M8 suitable for standard systems
- ● Long design for wide systems
- ● Sn distance for long-distance detection
- ● Plug-in – simple installation in machinery
Subscription products in your shopping cart
Set one delivery frequency for all subscription products in your cart every:
Subscription products in your shopping cart
An inductive sensor NIS08562 for industrial applications with a PBT sensing face stands out for its high mechanical resistance and stable operation.
M8 sensors were designed for applications requiring space-saving solutions. Ø8 x 60 mm sensors take up little space, supporting dense system designs.
Technical specification:
- Diameter: M8, commonly used in industrial automation
- Length: 60 mm, used in large industrial installations
- Sensing range: 4 mm
- Housing: Threaded housing sensor
- Housing material: Nickel-plated brass, used in standard industrial applications
- Sensing face material: PBT, stable dielectric properties for inductive field
- Mounting: Flush mounting
- Switching function: NC, used in safety functions
- Cable length: n/d
- Supply voltage: DC 10-30V, protection against typical voltage fluctuations
Applications
- Application in production lines of automotive components for detecting the presence of metal elements.
- Monitoring of processes in machining centers.
- Control of production line synchronization.
- Use in automatic assembly systems.
- Detection of position in internal transport systems.
Features and Benefits
- Stable operation in high-dynamic cycle environments
- Compatibility with standard industrial control systems
- Compatibility with industrial robots and EOAT systems
- Resistance to electromagnetic interference
When to choose this model
- Used in typical production lines and automation systems.
- Ensures good mounting compatibility.
- Used in assembly lines across many industries.
- Suitable for applications with stable operating conditions.
Connection
The sensor has an NPN output, so connect it with an M8 3-pin connection cable without LEDs. Cables with LEDs (NXOC08261…, NXOC08121…) have a yellow status LED wired for a PNP output and are not suitable for NPN sensors.
The diameter of an inductive sensor is a dimension that defines the width of the sensor element measured in millimeters. This is an important technical parameter as it affects the mounting method and the space required for installation.
Rated detection range is a key parameter of an inductive sensor.Indicates the distance at which the sensor changes its output state when a metal object approaches its front end axially.This is the sensor's most important functional feature—it determines how close the object being detected must be in order to be registered.
