Inductive sensor M30 78 mm connector M12 PNP NC Sn = 40 mm
- ● M30 housing for large applications
- ● Long enclosure for expanded applications
- ● Sensor with extended detection field
- ● Plug-in – splash- and water-resistant
Subscription products in your shopping cart
Set one delivery frequency for all subscription products in your cart every:
Subscription products in your shopping cart
An industrial inductive sensor NIS30454 with a PBT sensing face combines a compact design with high durability.
The M30 sensor fits into a range of solutions for heavy industry and mass production. Thanks to its large Ø30 x 78 mm dimensions, the sensor offers increased durability under intensive use.
Technical specification:
- Diameter: M30, designed for heavy industry
- Length: 78 mm, better resistance to vibration and stress
- Sensing range: 40 mm
- Housing: Threaded housing sensor
- Housing material: Nickel-plated brass, good protection against standard corrosion
- Sensing face material: PBT, stable dielectric properties for inductive field
- Mounting: non-flush mounting
- Switching function: NC, opens upon object detection
- Cable length: n/d
- Supply voltage: DC 10-30V, commonly used control supply
Applications
- Position control of parts in automotive assembly lines.
- Application in material feeding and unloading systems.
- Use in automation of packaging and sorting processes.
- Use in automatic assembly systems.
- Application in machine safety and interlock systems.
Features and Benefits
- High reliability in automated automotive production lines
- Compatibility with standard industrial control systems
- Stable detection in high-throughput processes
- High precision positioning of elements in robotic systems
- Long service life in continuous operation
When to choose this model
- Ensures highest mechanical resistance.
- Used in 24/7 installations.
- Used in large automation lines.
- Suitable for the most demanding environments.
The diameter of an inductive sensor is a dimension that defines the width of the sensor element measured in millimeters. This is an important technical parameter as it affects the mounting method and the space required for installation.
Rated detection range is a key parameter of an inductive sensor.Indicates the distance at which the sensor changes its output state when a metal object approaches its front end axially.This is the sensor's most important functional feature—it determines how close the object being detected must be in order to be registered.
