Inductive sensor M30 78 mm connector M12 NPN NC Sn = 25 mm
- ● Threaded M30 housing for mounting in a hole or bracket
- ● Longer module for expanded systems
- ● Sensor with wide operating range
- ● Plug-in – durable for everyday use
Subscription products in your shopping cart
Set one delivery frequency for all subscription products in your cart every:
Subscription products in your shopping cart
An industrial inductive sensor NIS30432 with a PBT sensing face is ideal for applications requiring durability and precise performance.
The M30 sensor ensures continuous operation in monitoring and control systems. The Ø30 x 78 mm format is designed for operation in demanding, high-load conditions.
Technical specification:
- Diameter: M30, designed for heavy industry
- Length: 78 mm, designed for demanding operating conditions
- Sensing range: 25 mm
- Housing: Threaded housing sensor
- Housing material: Nickel-plated brass, smooth surface for easier operation
- Sensing face material: PBT, stable dielectric properties for inductive field
- Mounting: non-flush mounting
- Switching function: NC, continuous signal monitoring in circuit
- Cable length: n/d
- Supply voltage: DC 10-30V, protection against typical voltage fluctuations
Applications
- Application in production lines of automotive components for detecting the presence of metal elements.
- Application in material feeding and unloading systems.
- Use in automation of packaging and sorting processes.
- Application in robotic axis positioning systems.
- Use in actuator and mechanism control systems.
Features and Benefits
- Stable operation in high-dynamic cycle environments
- Compatibility with standard industrial control systems
- Reliable operation in automated packaging systems
- Stable operation in dynamic automation systems
- Resistance to electromagnetic interference
When to choose this model
- Ensures highest mechanical resistance.
- Ensures very stable detection.
- Used in heavy transport systems.
- Used in systems requiring long detection range.
Connection
The sensor has an NPN output, so connect it with an M12 4-pin connection cable without LEDs. Cables with LEDs (NXOC12281…, NXOC12401…) have a yellow status LED wired for a PNP output and are not suitable for NPN sensors.
The diameter of an inductive sensor is a dimension that defines the width of the sensor element measured in millimeters. This is an important technical parameter as it affects the mounting method and the space required for installation.
Rated detection range is a key parameter of an inductive sensor.Indicates the distance at which the sensor changes its output state when a metal object approaches its front end axially.This is the sensor's most important functional feature—it determines how close the object being detected must be in order to be registered.
