Inductive sensor M30 53 mm connector M12 NPN NO Sn = 25 mm
- ● Larger-diameter M30 increases mounting flexibility
- ● Short housing for tight mounting spaces
- ● Sensor with greater detection distance
- ● Plug-in – easy setup and commissioning
Subscription products in your shopping cart
Set one delivery frequency for all subscription products in your cart every:
Subscription products in your shopping cart
An inductive sensor NIS30331 with a PBT sensing face offers high resistance to external factors and intensive operation.
A product in the M30 standard is a component of automation systems with increased durability. The Ø30 x 53 mm size allows stable operation in applications with strong vibration and mechanical forces.
Technical specification:
- Diameter: M30, designed for heavy industry
- Length: 53 mm, used in large industrial installations
- Sensing range: 25 mm
- Housing: Threaded housing sensor
- Housing material: Nickel-plated brass, smooth surface for easier operation
- Sensing face material: PBT,
- Mounting: non-flush mounting
- Switching function: NO, used in typical control applications
- Cable length: n/d
- Supply voltage: DC 10-30V, protection against typical voltage fluctuations
Applications
- Use in positioning and production synchronization systems.
- Application in material feeding and unloading systems.
- Application in packaging transport systems.
- Application in integration of industrial automation systems.
- Detection of position in internal transport systems.
Features and Benefits
- Stable operation in high-dynamic cycle environments
- Stable operation in CNC machines and automation systems
- Resistance to intensive cyclic operation
- Resistance to frequent cycles and micro-vibrations
- Long service life in continuous operation
When to choose this model
- Suitable for heavy industry and large installations.
- Suitable for dusty environments.
- Used in large-scale industrial installations.
- Used in systems requiring long detection range.
Connection
The sensor has an NPN output, so connect it with an M12 4-pin connection cable without LEDs. Cables with LEDs (NXOC12281…, NXOC12401…) have a yellow status LED wired for a PNP output and are not suitable for NPN sensors.
The diameter of an inductive sensor is a dimension that defines the width of the sensor element measured in millimeters. This is an important technical parameter as it affects the mounting method and the space required for installation.
Rated detection range is a key parameter of an inductive sensor.Indicates the distance at which the sensor changes its output state when a metal object approaches its front end axially.This is the sensor's most important functional feature—it determines how close the object being detected must be in order to be registered.
