Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm
Symbol: NIS30003-K2

Inductive sensor M30 35 mm cable 2m PNP NO Sn = 10 mm

+ Add to compareAdd to shopping list
  • ● M30 version simplifies component placement
  • ● Miniature version for precision machinery
  • ● Comfortable detection range for common processes
  • ● With cable – resistant to dirt and dust

28,47 €

net / 1pcs
Lowest price in 30 days before discount: / pcs
Regular price: / pcs
List price:
You can buy for pts.
of
You can also buy using:
Create a request for quotation
Custom product
Contact the shop staff, in order to estimate time of preparing this product for shipment.
Custom product
Shipment
Free and fast delivery from 18,72 €
30 days for free returns
This product is not available in a stationary store
Safe shopping
After purchase you will receive pts.
Files to download

NIS30003-K2

A Teflon-faced inductive sensor NIS30003-K2 is an excellent choice for automation systems where reliability and repeatable performance are essential.

The M30 sensor belongs to a series of devices designed for demanding applications., Dzięki dużym gabarytom Ø30 x 35 mm czujnik oferuje zwiększoną trwałość w intensywnej eksploatacji.

Technical specification:

  • Diameter: M30, designed for heavy industry
  • Length: 35 mm, stable mechanical construction
  • Sensing range: 10 mm
  • Housing: Threaded housing sensor
  • Housing material: Nickel-plated brass, stable mechanical properties of the material
  • Sensing face material: PBT,
  • Mounting: Flush mounting
  • Switching function: NO, normally open state at rest
  • Cable length: 2 m
  • Supply voltage: DC 10-30V, commonly used control supply

Applications

  • Quality and presence control of elements in production processes.
  • Application in CNC machines for position control of elements and tools.
  • Application in packaging lines for product presence detection.
  • Application in robotic axis positioning systems.
  • Use in actuator and mechanism control systems.

Features and Benefits

  • High detection precision in machining environments
  • Resistance to intensive cyclic operation
  • Stable operation in dynamic automation systems
  • Versatile use in different OEM machine types

When to choose this model

  • Used in applications requiring maximum detection range.
  • Suitable for dusty environments.
  • Suitable for very demanding applications.
  • Used in heavy-duty OEM systems.
Other information
Brand
Nexotec
Entity responsible for this product in the EU
Nexotec spółka z ograniczoną odpowiedzialnościąMore
ProducerNexotec spółka z ograniczoną odpowiedzialnościąAddress: Marii Kuncewiczowej 3Postal code: 41-706City: Ruda ŚląskaCountry: PolskaPhone number: +48 600 025 770E-mail: azakrzewski@nexotec.pl
Responsible entityNexotec spółka z ograniczoną odpowiedzialnościąAddress: Marii Kuncewiczowej 3Postal code: 41-706City: Ruda ŚląskaCountry: PolskaPhone number: 600025770E-mail: azakrzewski@nexotec.pl
Symbol
NIS30003-K2
Producer code
5907367823905
Series
NIS30
Warranty
Manufacturer's warranty for 2 years
General information
DiameterMore

The diameter of an inductive sensor is a dimension that defines the width of the sensor element measured in millimeters. This is an important technical parameter as it affects the mounting method and the space required for installation.

M30
Switching distance
10 mm
Mounting
Mounting Flush
Output function
PNP
Switching function
NO
Electrical data
Operating voltage
DC 10-30V
No load current
<10mA
Max load current
200mA
Leakage current
<0.01mA
Repeat accuracy
<1.0%sr
Short-circuit protection
YES
Overload trip point
220mA
Voltage drop
<1,5V
Ripple
<10%
Response time
0,5ms
Switching frequency
300Hz
Temperature drift
<10%sr
Switching hysteresis
<15%sr
Mechanical data
Housing shape
Threaded
Housing material
Nickel-plated brass
Material active face
PBT
LED display
YES
Dimensions
Ø30 x 35 mm
Sensor length
35 mm
Electrical connection
Connection type
Cable
Connector size
n/d
Number of pins
n/d
Cable length
2 m
Cable diameter
⌀ 5 mm
Cable
3 x 0,34 mm²
Cable material
PVC
Operating conditions
Protection category
IP67
Operating temperature min
-25℃
Operating temperature max
+70℃
Inne
Manufacturer code
NIS30003-K2
Condition
New
Packaging condition
Original
Type
Inductive
Weight in kg
0,1
Współczynnik redukcji
Fe37 steel
1
Aluminium
0,35 - 0,6
Brass
0,4 - 0,7
Copper
0,25 – 0,5
Stainless steel
0,8 - 1
Cast iron
0,95 - 1
Nikiel
0,6 - 0,75
Manufacturer's warranty for 2 years
