Inductive sensor M18 Metal face 48 mm connector M12 PNP NC Sn = 8 mm
- ● M18 intended for automation systems and production lines
- ● Compact execution for demanding tight locations
- ● Sensor with increased detection distance
- ● Tough metal enclosure design
- ● lug-in version – built for harsh conditions
Subscription products in your shopping cart
Set one delivery frequency for all subscription products in your cart every:
Subscription products in your shopping cart
A stainless steel face inductive sensor NMF18134 is ideal for industrial applications requiring maximum resistance to mechanical damage, impact, abrasion, and harsh operating conditions.
The M18 version has been specifically developed for dependable performance in challenging industrial conditions, including areas with metal particles, contamination, and mechanical loads., The larger Ø18 x 48 mm housing supports installation in systems requiring durable and reliable sensor mounting.
Technical specification:
- Diameter: M18, large diameter design providing extended detection range
- Length: 48 mm, easy integration with standard mounting systems and fixtures
- Sensing range: 8 mm
- Housing: Threaded sensor
- Housing material: Stainless steel housing
- Sensor face material: Stainless steel housing
- Mounting: Non-flush mounting, extended sensing range and maximum detection distance
- Switching function: NC, used in safety-related applications and monitoring functions
- Cable length: n/d
- Supply voltage: DC 10-30V, compatibility with PLC control systems and industrial automation networks
Applications
- They enhance quality control through reliable part presence detection and inspection processes.
- Detects the presence of workpieces in machining fixtures and clamping systems.
- Detects metal objects and components in packaging systems.
- Used in robotic systems for precise position monitoring of components.
- Used in OEM machine automation and control systems.
Features & Benefits
- Stable operation in high-speed and dynamic production environments.
- Reliable detection of workpiece and tool positions.
- Reliable operation in automated packaging systems.
- Reliable synchronization of machine and robot operation.
- Reliable performance in safety and control systems.
When to choose this model
- Suitable for operation in environments with high levels of vibration, impact, and mechanical stress.
- Selected for reliable detection of larger metal objects over extended sensing distances.
- Integrated into industrial conveyor systems, logistics automation, and heavy material handling equipment.
- Used in mass production environments where consistent performance is required over long periods.
The diameter of an inductive sensor is a dimension that defines the width of the sensor element measured in millimeters. This is an important technical parameter as it affects the mounting method and the space required for installation.
Rated detection range is a key parameter of an inductive sensor.Indicates the distance at which the sensor changes its output state when a metal object approaches its front end axially.This is the sensor's most important functional feature—it determines how close the object being detected must be in order to be registered.
