Inductive sensor M18 Metal face 35 mm cable 2m NPN NO Sn = 5 mm
- ● Precision M18 with a strong metal construction
- ● For mounting in hard-to-reach areas
- ● Proven sensing range for general use
- ● Robust housing for long-term use
- ● Cable version – moisture and dust resistant
Subscription products in your shopping cart
Set one delivery frequency for all subscription products in your cart every:
Subscription products in your shopping cart
NMF18021
A stainless steel inductive sensor NMF18021 delivers reliable detection performance in industrial automation, process control, machine monitoring, and heavy-duty production systems.
This M18 model represents a line of inductive sensors developed for demanding manufacturing and automation applications where rugged construction and reliability are essential., The Ø18 x 35 mm format is ideal for applications requiring extended sensing range and enhanced structural durability.
Technical specification:
- Diameter: M18, enhanced resistance to shocks, vibrations, and mechanical stress
- Length: 35 mm, tandard housing length used in industrial inductive sensors
- Sensing range: 5 mm
- Housing: Threaded sensor
- Housing material: Stainless steel housing
- Sensor face material: Stainless steel housing
- Mounting: Flush mounting, stable operating characteristics when installed in metal surfaces
- Switching function: NO, output activated when an object is detected
- Cable length: 2 m
- Supply voltage: DC 10-30V, stable operation in DC-powered automation applications
Applications
- They provide accurate object detection in automated vehicle manufacturing systems.
- Used in automated material feeding and handling systems.
- Detects metal objects and components in packaging systems.
- Monitors the position of robotic grippers and end-effectors.
- Supports equipment operating under high-duty cycle conditions.
Features & Benefits
- Easy integration with robotic systems and PLC control systems.
- Resistance to coolants, oils, and industrial contaminants.
- Reliable operation in automated packaging systems.
- Fast detection in pick-and-place processes.
- Resistance to electromagnetic interference.
When to choose this model
- Used in industrial transport systems and heavy automation applications requiring robust sensing technology.
- Selected for reliable detection of larger metal objects over extended sensing distances.
- Integrated into industrial conveyor systems, logistics automation, and heavy material handling equipment.
- Designed for long-term continuous operation with reduced risk of mechanical damage.
The diameter of an inductive sensor is a dimension that defines the width of the sensor element measured in millimeters. This is an important technical parameter as it affects the mounting method and the space required for installation.
Rated detection range is a key parameter of an inductive sensor.Indicates the distance at which the sensor changes its output state when a metal object approaches its front end axially.This is the sensor's most important functional feature—it determines how close the object being detected must be in order to be registered.
The manufacturer guarantees repair or replacement of the equipment for up to 24 months from the date of purchase. Contact the store via the complaint form to order a courier who will collect the equipment from your home.
